أدني كمية الطلب:1
نموذج: SEVKDK032A5M3P-GBT
1. المواصفات الأساسية
2. الوظائف الرئيسية
3. السلامة والجودة
4. التثبيت والاستخدام
يوصى باستخدام الأسلاك الصلبة لإدخال الطاقة؛ ارتفاع تركيب الجهاز ~ 1.5 متر من الأرض
يشتمل على خطاف كابل شحن، مناسب للوضع الداخلي والخارجي
|
Dimension |
350(H) × 240(W) × 95(D)mm |
|
User Interface |
Indicator light |
|
Installation method |
Wall-mounted Type/Floor-standing Type Installation |
|
Wiring method |
Bottom enter&out |
|
Cable length |
5M(16.4FT) standard,7.5m / 10m or other size customizable |
|
Weight |
8.0kg (Including charging gun) |
|
Input voltage |
380V |
|
Frequency |
45-65Hz |
|
Power rating |
22KW |
|
Measurement accuracy |
OBM 1.0 |
|
Output voltage |
AC380±20% |
|
Output current |
32A |
|
Standby power |
3KW |
|
Indicator light |
YES |
|
Display |
NO |
|
Design standard |
GB/T 20234 |
|
Protection |
Overvoltage protection, undervoltage protection, overload protection, short circuit protection, ground protection, over temperature protection, lightning protection,type A 30mA + 6mA DC leakage protection |
|
Working temperature |
-40-+65℃ |
|
Working Humidity |
5%-95% no condensation |
|
Working altitude |
≤3000m |
|
IP grade |
≥IP65 |
|
Cooling mode |
Natural cooling |
|
Applicable |
Indoor/Outdoor，No conductive dust, no corrosive gas, no explosive gas, no strong vibration |
|
Special protection |
UV resistance |
|
MTBF |
≥100000H |
|
Installation components |
Stand pillar (customize) |
|
Communication interface |
WIFI☑/4G□/LAN□/OCPP1.6□ |
|
RFID |
2 user cards☑ |
|
Leakage protection |
Upgrade to Type A 30mA AC + 6mA DC（three phase） |
|
Home load balancing |
DLB(customize) |
|
Socket outlet |
Change charging cable to socket(not support SAE standard) |
|
Product properties |
APP☑ |
